280A aR fast fuse YZPST-36LB81

Name of products:280A aR fast fuse YZPST-36LB81 Type of the products:YZPST-36LB81 Rated current:280A Rated voltage: AC690V Function level: aR Breaking capacity: AC=100kA   Product number    Rated voltage (V) Rated current (A) size (mm) A B C D G H J   YZPST-18LB64 AC690V 20-125 2 18.2 19 76 62 6.5 9 SI YZPST-21LB70 60-160 2.5 21.3 22 90 70 9 11 YZPST-24LB77 125-200 3 23 25.5 98 77 9 14 YZPST-27LB70 90-225 3 26.8 28 90 70 9 11 YZPST-36LB81 150-355 3 33 36 106 81 11 19 YZPST-48LB85 315-600 3.5 47.5 51 109 85 11 16 YZPST-38LB85 180-350 3 38 44 113 85 11 19     Type Size Current l2t(A2S) Power consumption (A) Pre-arc Fuse (W) YZPST-18LB64 18 25 25 150 7 32 32 190 10 35 52 310 11 40 100 600 12 45 105 680 13 50 120 780 14 56 135 950 15 63 170 1200 16 80 360 2500 18 100 500 3500 21 125 650 4500 25 YZPST-21LB70 21 60 200 800 16 80 250 900 18 100 360 1300 21 125 540 1900 27 140 850 2500 35 160 1000 3700 39 YZPST-24LB77 24 125 540 1900 27 140 850 2500 35 160 1000 3700 39 180 1400 5300 46 200 1900 7100 52 YZPST-27LB70 27 90 250 900 19 100 360 1300 21 125 540 1900 27 140 850 2500 36 160 1000 3700 40 180 1400 5300 46 200 1900 7100 52 225 3700 10500 55 YZPST-36LB81 36 150 2100 14000 35 160 2400 15000 36 180 3800 25000 38 200 6000 40000 40 225 8500 60000 44 250 11500 80000 46 280 16500 100000 48 315 19000 125000 53 355 22000 160000 55 YZPST-38LB85 38 180 3800 25000 38 200 6000 40000 40 225 8500 60000 44 250 11500 80000 46 280 16500 100000 48 315 19000 125000 53 355 22000 160000 55 YZPST-48LB85 48 315 8600 62000 51 350 13500 97000 54 400 21000 150000 60

Product Number: YZPST-36LB81
INQUIRY
  • Product Description
  • Name of products:280A aR fast fuse YZPST-36LB81

    Type of the products:YZPST-36LB81

    Rated current:280A

    Rated voltage: AC690V
    Function level: aR
    Breaking capacity: AC=100kA



    Product number



    Rated voltage

    (V)

    Rated current

    (A)

    size

    (mm)

    A

    B

    C

    D

    G

    H

    J



    YZPST-18LB64

    AC690V

    20-125

    2

    18.2

    19

    76

    62

    6.5

    9

    SI

    YZPST-21LB70

    60-160

    2.5

    21.3

    22

    90

    70

    9

    11

    YZPST-24LB77

    125-200

    3

    23

    25.5

    98

    77

    9

    14

    YZPST-27LB70

    90-225

    3

    26.8

    28

    90

    70

    9

    11

    YZPST-36LB81

    150-355

    3

    33

    36

    106

    81

    11

    19

    YZPST-48LB85

    315-600

    3.5

    47.5

    51

    109

    85

    11

    16

    YZPST-38LB85

    180-350

    3

    38

    44

    113

    85

    11

    19




    Type Size Current l2t(A2S) Power consumption
    (A) Pre-arc Fuse (W)
    YZPST-18LB64 18 25 25 150 7
    32 32 190 10
    35 52 310 11
    40 100 600 12
    45 105 680 13
    50 120 780 14
    56 135 950 15
    63 170 1200 16
    80 360 2500 18
    100 500 3500 21
    125 650 4500 25
    YZPST-21LB70 21 60 200 800 16
    80 250 900 18
    100 360 1300 21
    125 540 1900 27
    140 850 2500 35
    160 1000 3700 39
    YZPST-24LB77 24 125 540 1900 27
    140 850 2500 35
    160 1000 3700 39
    180 1400 5300 46
    200 1900 7100 52
    YZPST-27LB70 27 90 250 900 19
    100 360 1300 21
    125 540 1900 27
    140 850 2500 36
    160 1000 3700 40
    180 1400 5300 46
    200 1900 7100 52
    225 3700 10500 55
    YZPST-36LB81 36 150 2100 14000 35
    160 2400 15000 36
    180 3800 25000 38
    200 6000 40000 40
    225 8500 60000 44
    250 11500 80000 46
    280 16500 100000 48
    315 19000 125000 53
    355 22000 160000 55
    YZPST-38LB85 38 180 3800 25000 38
    200 6000 40000 40
    225 8500 60000 44
    250 11500 80000 46
    280 16500 100000 48
    315 19000 125000 53
    355 22000 160000 55
    YZPST-48LB85 48 315 8600 62000 51
    350 13500 97000 54
    400 21000 150000 60
