Charcoal Grey 101.6x50.8x25.4mm big size ferrite bar
- Product Description
-
YZPST-101.6x50.8x25.4 ferrite barDIMENSIONS(mm)
PARAMETETS
Core Factor C1
\ mm-1
Effective Length Le
\ mm
Effective Cross Area Ae
\ mm2
Effective Volume Ve
\ mm3
Apporx .Weight
645 g/set
MATERIAL CHARACTERISTICS
Characteristice Symbol Unit PTS40 Initial permeability ui \ 2300±25% mT 25℃ 510 Saturation flux density Bs （1000A/m） 100℃ 390 Remanence Br mT 120 Coercivity Hc A/m 13 25℃ \ Power loss Pc KW/m3 60℃ 550 f=100kHz，B=200mT 100℃ 410 Curie temperature Tc ℃ >230 Resistivity ρ Ω*m 6.5 Density d Kg/m3 ×103 4.8 Note ：The values were obtaioned with toroidal eores at room remperature unless otherwise shown Maximum chip off：
a. The depth of crack in the ground surface should be no more than 0.3mm,length is no more than 1/4, length of lengthen line. In the non-ground surface, the depth should be no more than 0.5mm length is no more than 1/3 length ot lengthen line.
PACKAGE:
